Yealink AX86R | A Well-Rounded Ruggedized Wi-Fi IP Phone for Clear Communications

SKU: YEA-AX86R 888VoIP is a Yealink Platinum Distributor in 2025!

You may also like…

Description

The AX86R is an enterprise portable Wi-Fi IP color screen phone that meets wireless communication needs. The AX86R meets the IP67 protection standard, effectively providing waterproof, dustproof, and 1.8-meter drop-proof capabilities. The AX86R supports registering up to 4 SIP accounts, 5-way local conferencing, and features a 2.4-inch color display. It integrates Yealink’s Optima HD Audio and Smart Noise Cancellation technology to deliver exceptional audio quality and clear voice communication. It is equipped with a built-in Bluetooth 5.0 module and a dual-band 2.4G/5G Wi-Fi 6 module, combined with advanced seamless roaming technology, allowing you to stay ahead in the ever-evolving wireless era. In addition, AX86R is equipped with a 3100mAh battery, providing a talk time of 13 hours and a standby time of 300 hours. It is widely used in various wireless scenarios such as SMEs, offices, warehouses, supermarkets, and hotels.

Core Features:

  • IP67-rated waterproof and dustproof, drop-proof up to 1.8 meters
  • 2.4″ 240×320 TFT color screen
  • Up to 13-hour talk time (in ideal conditions)
  • Up to 300-hour standby time (in ideal conditions)
  • Dual Band 2.4G/5G Wi-Fi 802.11 a/b/g/n/ac/ax
  • Support IEEE802.11k/v/r roaming
  • Bluetooth 5.0 for headset
  • HD audio, noise cancellation and acoustic shield
  • TRANS and Mute keys, 11 configurable keys
  • Up to 4 SIP accounts
  • Local 5-way conferencing
  • No Perception Upgrade
  • Type-C charging
  • Wall mountable and stand mountable
  • Support YDMP/YMCS

Additional information

Weight 1.08 lbs
Dimensions 7.13 × 4.09 × 3.54 in
Brand

Yealink
Phone Type

DECT, WiFi / WiFi Capable
Wi-Fi Standard

Wi-Fi 6 (802.11ax)
GENERAL
  • Model: AX86R
  • Part number: 1301221
  • UPC Code: 841885126023
  • EAN Code: 6938818322035
AUDIO FEATURES
  • Optimal HD audio: HD handset, HD speaker
  • Hearing aid compatible (HAC) compliant
  • Acoustic Shield
  • Audio codec: G.722, PCMU (G.711μ), PCMA (G.711A), G.729,
    G.729A, G.729B, G.729AB, G.726, G.723.1, iLBC
  • DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
  • Full-duplex hands-free speakerphone with AEC
  • Dual Noise-Canceling Microphones
  • Smart Noise Cancellation Technology
  • VAD, CNG, AEC, PLC, AJB, AGC
DISPLAY AND INDICATOR
  • 2.4″ 240×320 TFT color screen
  • Keypad backlight
  • Vibration
  • Wallpaper and screensaver
  • LED for call and message waiting indication
  • Multilingual user interface
  • Caller ID with name, number, and avatar
PHONE FEATURES
  • 4 VoIP accounts
  • Speed dial, redial
  • Call hold/call transfer/call waiting/call forward
  • Emergency call
  • Mute, DND
  • Auto answer
  • Hotline
  • Recall
  • Local 5-way conferencing
  • Direct IP call without SIP proxy
  • Ring tone selection/import/delete
  • Set date time manually or automatically
  • Dial Plan, XML Browser, Action URL/URI
  • RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
  • Customizable softkey
PERIPHERALS
  • Support Bluetooth headset
    • Basic functions: answer/end/mute call
    • Enhanced functions: redial/call hold/volume adjustment two-way synchronization
IP-PBX FEATURES
  • Anonymous call, anonymous call rejection
  • Intercom
  • Multicast paging
  • Call completion
  • Message Waiting Indicator (MWI)
  • Call Park, call pickup
  • Call recording
  • Voice mail
FEATURE KEYS
  • 3 soft keys
  • 6 function keys: dial, hang up, hands-free, voice message, mute, call transfer
  • Navigation key and OK key
  • Volume control keys
  • Alarm Key
  • PTT Key
INTERFACE
  • 1 x 3.5 mm headset jack
  • 1 x Type-C port
NETWORK
  • Built-in dual-band Wi-Fi:
    • Network standard: 2.4G&5G IEEE802.11a/b/g/n/ac/ax
    • Frequency range: 2.4 GHz/ 5.0 GHz
    • Roaming: IEEE802.11 k/r/v
  • Built-in Bluetooth 5.0:
    • Connecting to Bluetooth Headset
  • IPv4/IPv6
  • SIP v1 (RFC2543), v2 (RFC3261)
  • Call server redundancy supported
  • NAT traversal: STUN mode
  • SIP link mode: Proxy mode and peer-to-peer
  • IP Assignment: static/DHCP
  • HTTP/HTTPS web server
  • Time and date synchronization using SNTP
  • UDP/TCP/DNS-SRV (RFC 3263)
  • QoS: Layer 3 ToS DSCP, 802.11e/WMM
SECURITY
  • SRTP for voice
  • TLS1.3 support
  • HTTPS certificate manager
  • AES encryption for configuration file (AES256)
  • Digest authentication using MD5/MD5-sess
  • OpenVPN, IEEE802.1X
  • WPA, WPA2, WPA3
  • Secure boot
  • GARP (Generic Attribute Registration Protocol)
POWER
  • Power adapter: AC 100~240V input and DC 5V/2A output ENVIRONMENTAL FACTORS
  • Operating humidity: 10%-95%
  • Operating temperature: 0 to 40°C (+32 to 104°F)
  • Storage temperature: -30 to 70℃
OTHER PHYSICAL FEATURES
  • Safe drop height: 1.8 m
  • Protection rating: IP67
  • Chemical cleaning resistant
  • Antibacterial design
  • Battery: 3100mAh, Rechargeable Lithium-ion Battery, 3.7V, 11.47Wh
    • Up to 13-hour talk time (in ideal conditions)
    • Up to 300-hour standby time (in ideal conditions)
  • Package Contents
    • Yealink AX86R Phones
    • Charger Cradle
    • Rechargeable Battery
    • Belt Clip
    • Quick Start Guide
    • Power Adapter
For a full list of specifications, please refer to the product datasheet.
