SKU: PEP-ANT-MR-20G-N-W-6

Peplink ANT-MR-20G-N-W-6

Login to view prices

MSRP: $449.00

Peplink Maritime 20G | 2×2 MIMO 5G Ready Cellular Antenna System with GPS

SKU: PEP-ANT-MR-20G-N-W-6

You may also like…

Description

Peplink Maritime 20G, ANT-MR-20G-N-W-6

Core Features:

  • 2×2 MIMO 5G Ready Cellular Antenna System with GPS
  • 2xLTE/5G, 1xGPS
  • 600-6000MHz
  • IP68, N-Type, White, 6.5 ft / 2m

* 1″ 14TPI male adapter (ACW-652) is not included

Additional information

Weight 8.4 lbs
Dimensions 26.3 × 6 × 6.1 in
Brand

Peplink
Accessory Type

Antennas

GENERAL INFO:

  • Model: Maritime 20G
  • Product code: ANT-MR-20G-N-W-6

CELLULAR:

  • Antenna elements: 2 elements
  • Cellular frequency bands & Gain:
    • 3.2dBi: 410-470MHz
    • 5.4dBi: 617-960MHz
    • 4.9dBi: 1710-2700MHz
    • 6.2dBi: 3400-4200MHz
    • 6.8dBi: 4900-6000MHz
  • VSWR
    • <2.5: 410-470MHz
    • <3.0: 617-960MHz
    • <2.5: 1710-6000MHz
  • Max feed power handling 10W
  • Input impedance 50 Ω
  • Polarisation Linear

GPS:

  • Frequency range 1561-1602 MHz
  • Peak gain:
    • 0.5dBi@1575MHz
    • 1.6dBi@1602MHz
  • VSWR: < 2.5
  • Output return loss: 10dB max
  • LNA gain: 28 ±3dB
  • Noise figure: 1.5dB max at 3.3V
  • Operating Voltage: 3.3V
  • Power consumption: 8.5mA ±2.5m at 3.3V

CABLE (LTE/5G):

  • Type: CFD-200
  • Length: 6’7″ / 2m
  • Loss:
    • 0.33 dB/m @ 900 MHz
    • 0.49 dB/m @ 2000 MHz
    • 0.55 dB/m @ 2500 MHz
    • 0.87 dB/m @ 5800 MHz
  • Diameter: 13/64″ / 5.0mm
  • Jacket: Half matt PVC, UV resistant
  • Termination: N-type female

For a full list of specifications, please refer to the product datasheet
