InVid VIS-P5BXIR180NH-AI

Login to view prices

MSRP: $280.00

InVid VIS-P5BXIR180NH-AI | 5 Megapixel IP Plug & Play, Outdoor Bullet, 180 Degree Wide Angle View, Up to 66’ IR Range, WDR, Built-in Mic, SD Card Slot, 12VDC/PoE

SKU: INV-VIS-P5BXIR180NH-AI

You may also like…

Description

InVid VIS-P5BXIR180NH-AI, 5 Megapixel IP Plug & Play, Outdoor Bullet, 180 Degree Wide Angle View, Up to 66’ IR Range, WDR, Built-in Mic, SD Card Slot, 12VDC/PoE

Core Features:

  • True AI Human and Vehicle Classification for Line Crossing and Intrusion Detection
  • 180 Degree Wide Angle View
  • 5 Megapixel Resolution
  • LED Distance Up to 66ft
  • Ultra 265, H.265, H.264, MJPEG
  • 30 FPS Recording and Live
  • True WDR 120dB
  • Cloud Upgradeable
  • Micro SD Slot: Up to 256GB
  • Built-in Mic
  • IP67 Weatherproof
  • 12VDC/PoE Operation
  • ONVIF
  • Free iOS & Android Apps for Smart Phones & Tablets
  • Vision CMS
  • Free MAC Client

Additional information

Weight 0.93 lbs
Dimensions 7.8 × 2.8 × 2.8 in
Brand

InVid
IP Camera Audio Input

Built-in Mic
IP Camera Housing Material

Metal
IP Camera IR Range

51-100 ft
IP Camera Lens

Fixed
IP Camera Light Options

IR
Camera Megapixels

5 MP
IP Camera Type

Bullet
IP Camera Weather Rating

IP67 Weatherproof
Specialty Camera Features

Body Detection, Human Body Detection, True Human Body + Vehicle Detection

GENERAL INFO:

  • Model: VIS-P5BXIR180NH-AI
  • Power: DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 5.5W
  • Power Interface: Ø 5.5mm coaxial power plug
  • Dimensions (L × W × H): 7.8” × 2.8” × 2.8” (198× 71 × 71mm)
  • Weight: 0.93lb (0.42kg)
  • Material: Metal
  • Working Environment: -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing)
  • Storage Environment: -22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing)
  • Surge Protection: 4KV
  • Reset Button: Support

Camera:

  • Sensor: 1/2.7″, 5.0 megapixel, progressive scan, CMOS
  • Minimum Illumination Colour: 0.01lux (F2.0, AGC ON) 0 lux with IR on
  • Day/Night: IR-cut filter with auto switch (ICR)
  • Shutter: Auto/Manual, 1 ~ 1/100000s
  • Adjustment angle:
    • Pan: 0° ~ 360°
    • Tilt: 0° ~ 90°
    • Rotate: 0° ~ 360°
  • WDR: 120dB
  • S/N: >56dB

Lens:

  • Lens type: 1.68mm@F2.0
  • Iris: Fixed
  • Field of View (H): 180°
  • Field of View (V): 100°
  • Field of View (O): 180°

Image:

  • White Balance: Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
  • Digital Noise Reduction: 2D/3D DNR
  • Smart IR: Support
  • Flip: Normal/ Flip Vertical/ Flip Horizontal/180°
  • Dewarping: Support
  • HLC: Support
  • BLC: Support
  • Defog: Digital Defog

For a full list of specifications, please refer to the product datasheet
