SKU: GRA-GWN7806P

Grandstream GWN7806P

Login to view prices

MSRP: $575.00

Grandstream GWN7806P Enterprise Layer 2+ Managed PoE Network Switch, 48 x GigE, 6 x 10Gigabit SFP+

SKU: GRA-GWN7806P

Related Blog Posts

Introducing the GWN7800 Series of Layer 2+ Network SwitchesJul 8th, 2024Read More

You may also like…

Description

The GWN7806(P) is layer 2+ stackable(pending) managed network switch that allows small-to-medium enterprises to build scalable, secure, high performance and smart business networks that are fully manageable. It supports advanced VLAN for flexible and sophisticated traffic segmentation, advanced QoS for prioritization of network traffic, IGMP/MLD Snooping for network performance optimization, and comprehensive security capabilities against potential attacks. The GWN7806P provides smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points and other PoE endpoints. GWN7806(P) is easy to deploy and manage, including managed by the local Web user interface of the GWN7806(P) switch and CLI, the command-line interface. The switch is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premises network management platform. The GWN7806(P) is the best value enterprise-grade managed switch for small-to-medium businesses.

Core Features:

  • 48 Gigabit Ethernet ports and 6 10Gigabit SFP+ ports
  • Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
  • Supports deployment in IPv6 and IPv4 networks
  • Reliability features including fault detection, device protection, dual boot, dual system file redundancy, link aggregation, storm control, and more
  • ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
  • Embedded controller to manage switch; GWN. Cloud and GWN Manager, Grandstream’s cloud and on-premises Wi-Fi management platform
  • Built-in QoS allows for prioritization of network traffic
  • Supports stacking (pending) for easy management of up to 16 switches in one interface while creating redundant backup between multiple devices

Additional information

Weight 11.68 lbs
Dimensions 21.54 × 17.95 × 4.21 in
Brand

Grandstream
Product Family

GWN-Cloud
Switch Type

Managed Switches, PoE Switches
Number of Ports

48-52
Main Port Speed

Gigabit
Uplink Ports

10G SFP+
Layer Support

L2+
PoE Support

Yes
PoE Budget

High (≥200)
Redundant Power Supply

No

GENERAL INFO:

  • Model: GWN7806P
  • Package Contents:
    • GWN7806P Switch
    • 1x 1.2m(10A) AC Cable
    • 1x 25cm Ground Cable
    • 4x Rubber Footpads
    • 2x Rack-Mounting Kits
    • 8x Screws (PM 3*6),
    • 1x Power Cord Anti-Trip
    • 1x Quick Installation Guide
  • Network Protocols:
    • IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad,
      IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
  • Gigabit Ports:
    • 48
  • 10Gigabit SFP+ Ports: 6
    Note: Support DAC cable, and must be ≤ 5m
  • Maximum no. of Supported Modules:
    • SM-10G: 6
    • MM-10G: 6
    • RJ45-10G: 3
      Note: RJ45-10G modules must be interval inserted
  • Console:
    • 1
  • # of PoE Ports:
    • 48
  • Integrated Power Supply:
    • 470W
  • Maximum Output Power Per PoE Port:
    • 30W
  • Max Total PoE Output Power:
    • 400W
  • PoE Standards:
    • IEEE 802.3af/at
  • Surge Protection:
    • ± 6KV CM and DM for power
    • ± 4KV CM for network ports
  • ESD:
    • ± 12KV for contact discharge
  • Auxiliary Ports:
    • 1x Reset Pinhole
  • Forwarding Mode:
    • Store-and-forward
  • Total non-blocking throughput:
    • 108Gbps
  • Switching Capability:
    • 216Gbps
  • Forwarding Rate:
    • 160.704Mpps
  • Packet Buffer:
    • 16Mb
  • Network Latency:
    • <4µs
  • Switching:
    • 32K static, dynamic and filtering MAC addresses
    • 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
    • VLAN virtual interface
    • 27 link aggregation
    • Spanning tree, 64 instances for STP/RSTP/MSTP
  • Routing:
    • Static routing
  • Multicast:
    • IGMP Snooping
    • MLD Snooping
  • QoS/ACL:
    • Port priority
    • Priority mapping
    • Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ
    • Traffic shaping
    • Rate limit
    • 4K ACL for Ethernet, IPv4 and IPv6
  • DHCP:
    • DHCP server, DHCP relay, DHCP Option 82, 60, 160 and 43
  • Mounting:
    • Desktop, Rackmount (rack-mounting kits included)
  • LEDs:
    • 1x tri-color LED for device tracking and status indication
    • 54x green-color LEDs for data transferring
    • 48x yellow-color LEDs for PoE powered
  • Environmental:
    • Operation: 0°C to 45°C, humidity: 10% to 90% RH(Non-condensing)
    • Storage: -10°C to 60°C, humidity: 10% to 90% RH(Non-condensing)
  • Dimensions:
    • 440mm(L)x301mm(W)x44mm(H)
  • Unit Weight:
    • 5.1Kg

For a full list of specifications, please refer to the product datasheet
