Description
Description
The GCC6010 Series provides an extraordinary all-in-one solution that redefines the communications experience by merging your unified communications and networking solutions into one platform. These state-of-the-art devices combine the functionality of 4 products to provide an all-in-one solution that includes a VPN router, next-generation firewall, IP PBX, and network switch or Wi-Fi access point. With the GCC Series, you can create and manage wired, wireless, and VPN networks, provide bank-grade network security, and utilize a market-leading communication and collaboration platform. These flexible devices provide unified management and centralized control of all Grandstream endpoint solutions, including Wi-Fi APs, network switches, IP Phones, and more. The GCC Series allows full UC and networking solutions to be configured in minutes and managed through the cloud with Grandstream Device Management System (GDMS), and can also be managed through our mobile app, local Web UI, and CLI console management. Ideal for small-to-medium sized businesses, the GCC6010 Series provides an all-in-one platform that combines all business data, communication, and collaboration needs into one device – making it easier and more affordable than ever to build state-of-the-art communication solutions.
Core Features:
- Built-in IPPBX (10 Users, 4 Concurrent Calls)
- Enterprise-grade firewall
- VPN Router
- 2 x 2.5 Gb, 5 x GigE Network Switch
- Easily configure, deploy, and manage all Grandstream endpoint
solutions from one central location - Supports SD-WAN for improved network performance, increased
security, and simplified network management - GWN6010W includes a built-in dual-band Wi-Fi 6 AP with 2×2
MIMO technology
Additional information
Additional information
Weight | 2.61 lbs |
---|---|
Dimensions | 11.26 × 4.98 × 4.13 in |
Brand | Grandstream |
Wi-Fi Standard | Wi-Fi 6 (802.11ax) |
Network Band | Dual Band |
Frequency Band | 2.4 Ghz, 5 Ghz |
Business Router | VPN Routers |
Network Type | Wired, Wireless |
Form Factor | Desktop |
WAN Port Count | 5-10 |
WAN Failover | Yes |
Technical Specifications
GENERAL INFO:
- Model: GCC6010W
- Wi-Fi Standards: IEEE 802.11 a/b/g/n/ac/ax
- Antennas:
- 3 individual internal antennas ( 2 x dual band + 1 x single band 5G)
- 2.4GHz: maximum gain 4.5dBi
- 5 GHz: maximum gain 5dBi
- Wi-Fi and System Security: WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3,
anti-hacking secure boot and critical data/control lockdown via digital signatures,
unique security certificate and random default password per device - Memory: 2GB RAM, 32GB eMMC Flash
- External Storage: N/A
Box Contents:
- GCC6010W, Universal Power Supply, Network Cable, Quick Installation Guide
Frequency Bands:
- 2.4GHz radio: 2400 – 2483.5 MHz
(2412-2472MHz is channel central frequency range; 2400-2483.5MHz is Frequency band)
5GHz radio: 5150 – 5895 MHz
*Not all frequency bands can be used in all regions
Channel Bandwidth:
- 2.4G: 20 and 40 MHz
5G: 20, 40, 80, 160 MHz
MU-MIMO:
- 2×2:2 2.4GHz
3×3:3 5GHz
For a full list of specifications, please refer to the product datasheet
